Product Capability

Operating  24/7, 365 days a year…. an effort to be better every day
Contact Us

  • Currently 19  film extrusion lines:

      • nine    mono layer

      • seven 3-layer

      • one     5-layer

      • two     9-layer Cast line

  • 160,000 sq² (production, office, warehouse)

Co-ex Film

We produce Polyethylene, Polypropylene, Nylon, EVOH in BLOWN and CAST film ranging from 6” to 118”, in gauges ranging from 0.0009 mil to 16 mil. Lead times and customer service are exceptional, our management team and operators have more than 40 years’ experience in the plastics industry. Our extrusion facility has 16 blown film lines and 2 Cast lines.

PRODUCT

SIZE RANGE

GAUGE

SINGLE WOUND SHEETING (SMALL WIDTHS)

10” – 35″

1.00 – 12.0 mil

SINGLE WOUND SHEETING (LARGER WIDTHS)

36” – 107”

1.00 – 12.0 mil

CF SHEETING

20” – 106”

0.8 – 8.0 mil

TUBING

36” – 106”

0.75 – 8.0 mil

J Sheeting

MAXIMUM ROLL OD   = 40”

Co-ex Films

Product Capability

3-Layer Performance Co-ex Films

3 – LAYER SPECIALTY SEALANT FILMS

 A / B / C  –  A / A / B  –  A / B / A

A – LAYER
LAMINATION OR HEAT RESISTANT LAYER
CORONA TREATMENT
COLOR ADDITIVES
MATERIALS AVAILABLE:
  • LDPE
  • EVA
  • LLDPE
  • MLLDPE – PLASTOMER
  • HDPE
  • PP
B – LAYER
CORE OR TIE LAYER
INCORPORATE TRIM / PCR
COLOR ADDITIVES
MATERIALS AVAILABLE:
  • LDPE
  • EVA
  • HDPE
  • PP
  • LLDPE
  • MLLDPE
  • TIE / ADHESIVE LAYER
C – LAYER
SEALANT LAYER
MODIFIED TO PROVIDE LOW,
MEDIUM OR HIGH COF
MATERIALS AVAILABLE:
  • LDPE
  • LLDPE
  • MLLDPE – PLASTOMER
  • EVA
  •  SURLYN
  • PEELABLE

Cast Film



PRODUCT

SIZE RANGE

GAUGE

SINGLE WOUND SHEETING (SMALL WIDTHS)

26″ – 47″

1.00 – 16.0 mil

SINGLE WOUND SHEETING (LARGER WIDTHS)

52” – 94”

1.00 – 16.0 mil

MAXIMUM ROLL OD for Cast PE films  = 36”

MAXIMUM ROLL OD for Cast PP films  = 30″

CORONA TREATMENT   ONE SIDE or BOTH SIDES

Cast Film

Product Capability

3 – LAYER PERFORMANCE CAST FILMS

9 – LAYER SPECIALTY SEALANT / BARRIER FILMS

 A / B / C / D / C/ E/ F /F/ G

5 – LAYER SPECIALTY SEALANT / BARRIER FILMS

 A / B / C / D / E/ G

A-Layer

*LDPE, LLDPE – * MLLDPE – *PLASTOMER – *EVA  *EAA / EMA – *Nylon – *HDPE – *PP

B-Layer

* Tie – *LDPE, LLDPE – *HDPE – *PP

C-Layer

*Tie – *LDPE, LLDPE – *HDPE – *Nylon – *PP

D-Layer

*EVOH – * Tie – * LDPE, LLDPE – * PP

E-Layer

* Tie – * Nylon – *LDPE, LLDPE – * PP

F-Layer

* Tie – * Nylon – *LDPE, LLDPE – * PP

G-Layer

*LDPE, LLDPE – *MLLDPE – *PLASTOMER *EVA – *EAA/EMA *PEELABLE *PP

Industrial Film

PRODUCT

SIZE RANGE

GAUGE

SINGLE WOUND SHEETING (SMALL WIDTHS)

4.5” – 10”

1.25 – 12.0 mil

SINGLE WOUND SHEETING (LARGER WIDTHS)

11” – 108”

0.5 – 12.0 mil

CF SHEETING

9” – 108”

0.8 – 8.0 mil

GUSSETED SHEETING

UP TO 150” BUBBLE

0.75 – 4.0 mil

TUBING (min gauge for 1up 16″-24″ = .002)

16” – 108”

0.75 – 8.0 mil

TUBULAR BAGS AND SLEEVES ON ROLL

(SMALL WIDTHS)

8” – 23”

0.75 – 2.5 mil

TUBULAR BAGS AND SLEEVES ON ROLL

(LARGER WIDTHS)

24” – 88”

0.6 – 8.0 mil

GUSSETED BAGS ON ROLL (SMALL WIDTHS)

8”x6” – 12”x11

0.75 – 2.5 mil

GUSSETED BAGS ON ROLL (LARGER WIDTHS)

12”x12” – 75”x75”

0.5 – 6.0 mil

CF BAGS ON ROLL

16” – 88”

0.8 – 8.0 mil

LOOSE TUBULAR BAGS AND SLEEVES

(SMALL WIDTHS)

12” – 23”

0.8 – 2.5 mil

LOOSE TUBULAR BAGS AND SLEEVES

(LARGER WIDTHS)

24” – 60”

0.8 – 6.0 mil

LOOSE GUSSETED BAGS (SMALL WIDTHS)

8” x 6” – 12’x11”

0.6 – 2.5 mil

LOOSE GUSSETED BAGS (LARGER WIDTHS)

12” x12” – 35”x35”

0.75 – 4.0 mil

LOOSE SHEETS

7” – 60”

0.75 – 8.0 mil

Products

COMBO LINERS AND CAPS, SMALL BAGS, BOX LINERS, PERFORATED SHEETS, FORM/FILL/SEALFILMS, CAN LINERS, BUNDLING

AND SHRINK FILMS, SHRINK BAGS, PALLET COVERS, CONVERTERGRADE SHEETING, LIP TUBING, INDUSTRIAL PRINTING (1C/1S).

Specification

MINIMUM ROLL OD = 6”

MAXIMUM ROLL OD = 40” (LINE 3 ONLY— SWS ONLY— 14” DIE). OTHERWISE 30” MAX.

MINIMUM RUN GAUGE = 0.5 mil

MAX GAUGE FOR SLIT SEAL = 4.0 mil

MINIMUM LENGTH = 18” FOR SMALLER DIES AND 36” FOR LARGER DIES

MAX LENGTH FOR LOOSE = 65” (DEPENDING ON GAUGE)

PINHOLES = MINIMUM 2X2

VENTS = 1/4” AND 3/8” FULL, BUTTERFLY, AND X

DOUBLE BOTTOM SEAL ON 10” DIES

PRINTING CAPABILITY OF ONE COLOR/ONE SIDE RANDOM PRINTING (SIZE VARIES)

Materials Technology

  • Polyethylene

LDPE, Linear LDPE

Metallocene LLDPE and MDPE

HDPE

PE plastomer



  • Polyethylene Copolymer

EVA, EAA, EMA

Peelable polymer technology



  • Polypropylene, polypropylene copolymer

  • EVOH

  • Nylon and nylon copolymer

  • Extrudable adhesive polymers

  • Functional additives/colors



              • Slip, antiblock

              • Antistat

              • Antifog

              • Antioxidant

              • UV inhibitor

              • UV absorber

              • Flame retardant

Summary

  • Innovative producer of high quality converter films
  • High quality wide web films
  • Customer driven and customer focused
  • Technically innovative supplier who thrives on challenges
  • Committed to development of customer partnerships
